Specifications
- Manufacturer: John Deere
- Model: 3032E
- Year: 2025
- Type: Compact tractor
- Engine power (gross): 22.9 kW
- Power take-off (PTO) power: 18.6 kW
- Steering hydraulics: 15 L/min
- Implement hydraulics: 20.2 L/min
- Hitch type: Category 1
- Lift capacity, 24-in. behind link arms: 615.1 kg
- Standard transmission; forward/reverse: Hydrostatic transmission (HST)
- Cruise control: Optional
- Approximate shipping weight (open-station; cab): 1007.9 kg
- Wheelbase: 159.5 cm
- Family: EYDXL1.64NDA
- Manufacturer: Yanmar
- Engine model: 3TNV88C-NJT
- Engine power (gross): 22.9 kW
- Power take-off (PTO) power: 18.6 kW
- Rated engine speed: 2500 rpm
- Type: Diesel
- Injection pump type: High pressure common rail direct injection
- Aspiration: Natural
- Emissions compliance: Final Tier 4
- Cylinders/displacement: 3 / 1.64 L
- Number of cylinders: Three
- Cylinder liners: Cast-in-block
- Bore and stroke: 88 x 90 mm
- Compression ratio: 19.1:1
- Lubrication: Pressurized
- Cooling system: Water pump
- Air cleaner: Dual element
- Engine torque at rated speed: 87 Nm
- Fuel tank capacity: 28.5 L
- Battery size: 500 CCA
- Alternator (12-V): 55 amp
- Starter size: 1.4 kW
- Type: High pressure common rail direct injection
- Standard transmission; forward/reverse: Hydrostatic transmission (HST)
- Left-hand reverser: No
- Final drive: Bull Gear
- Brakes: Wet disc
- Steering: Power steering
- Axle capacity: Front
- Creeper: No
- Cruise control: Optional
- Differential lock: Yes
- Type: Open center
- Pump rated output: Steering
- Pump type: Dual gear
- Maximum operating pressure: 172.4 bar
- Draft control sensing: Position control
- Remote control valves available: Up to two (optional)
- Type: Category 1
- Lift capacity, 24-in. behind link arms: 615.1 kg
- Standard: 540 rpm at 2500 rpm
- Control: Independent
- Clutch: Wet disk
- Brake (for mid and rear PTO): Wet disk
- Crankcase with filter: 4.5 L
- Type: Bull Gear
- Rollover protective structure: Type
- Platform - flat/straddle: Semi-flat
- Gear shift location - console/floor: Left-hand side
- Wheelbase: 159.5 cm
- Front axle clearance: 36.3 cm
- Turning radius without brakes: 2.9 m
- Approximate shipping weight (open-station; cab): 1007.9 kg
- Front: Farm - 7-14
- Rear: Farm - 11.2-24
