Specifications
- Manufacturer: John Deere
- Model: 3025D
- Year: 2025
- Type: Compact tractor
- Engine power (gross): SAE J1995 rated power: 18.2 kW
- Power take-off (PTO) power: 15.4 kW
- Steering hydraulics: 14.4 L/min
- Implement hydraulics: 19.2 L/min
- Hitch type: Category 1
- Lift capacity, 24-in. behind link arms: 944 kg
- Standard transmission; forward/reverse: 8F/8R synchromesh shuttle shift gear transmission
- Cruise control: No
- Approximate shipping weight (open-station; cab): Open operator station (OOS): 1260 kg
- Wheelbase: 1574 mm
- Manufacturer: Yanmar®
- Engine model: 3TNV88F-EPJPT
- Engine power (gross): SAE J1995 rated power: 18.2 kW
- Power take-off (PTO) power: 15.4 kW
- Rated engine speed: 2400 rpm
- Injection pump type: Direct injection
- Aspiration: Natural
- Emissions compliance: Final Tier 4
- Cylinders/displacement: 3 / 1.64 L
- Number of cylinders: Three
- Cylinder liners: Cast-in-block
- Bore and stroke: 88 x 90 mm
- Compression ratio: 19.1:1
- Lubrication: Pressurized
- Cooling system: Liquid
- Air cleaner: Dual element
- Engine torque at rated speed: 72.4 Nm
- Fuel tank capacity: 36.7 L
- Battery size: 600 CCA
- Alternator (12-V): 55 amp
- Starter size: 1.4 kW
- Type: Direct injection
- Standard transmission; forward/reverse: 8F/8R synchromesh shuttle shift gear transmission
- Left-hand reverser: Yes
- Transmission gear ranges: Four gears and two ranges
- Final drive: Spur gear
- Brakes: Wet disk
- Steering: Power steering
- Axle capacity: Front
- Creeper: No
- Cruise control: No
- Differential lock: Yes
- Type: Open center
- Pump rated output: Steering
- Pump type: Single gear
- Maximum operating pressure: 172 bar
- Draft control sensing: Position control
- Remote control valves available: Up to two (optional)
- Type: Category 1
- Lift capacity, 24-in. behind link arms: 944 kg
- Standard: At 2400 rpm: 540 rpm
- Control: Mechanical
- Clutch: Transmission
- Brake (for mid and rear PTO): Wet disk
- Crankcase with filter: 4.5 L
- Transmission and hydraulic system: 33 L
- Type: Spur gear
- Rollover protective structure: Type
- Platform - flat/straddle: Straddle
- Gear shift location - console/floor: Right-hand side
- Wheelbase: 1574 mm
- Front axle clearance: Minimum: 331 mm
- Turning radius with brakes: 1.63 m
- Approximate shipping weight (open-station; cab): OOS: 1260 kg
- Front: R1 Bar: 7-14
- Rear: R1 Bar: 11.2-24
- Toolbox: Yes
- Tilt steering wheel: No
- 12-V Outlet: No
